4-axis machine in TOP - equipment with self-adjusting
work table "VARIO"

Working field:
X-axis 3,200 mm
Y - axis 1,445 mm (milling area with cutter diameter 25 mm)
Z - stroke max. 325 mm
Drive-over height with 2-stage milling spindle 428 mm

6 workpiece supports, pneum. Clamped with 4 pcs. Suction consoles.
Each suction console is equipped with 2 vacuum suction cups
Automatically setting up the table in the X and Y direction.

Stop rows in X - direction front and back

Vacuum pump 140 cbm/h

6 pcs. Lifting rails for heavy workpieces

Main spindle 11 kW HSK F63
clockwise rotation
Speed ​​1,000 - 24,000 rpm
two-stage pre-stroke
liquid cooling
pneumatic Height-adjustable suction hood

C axis 360 degrees endlessly rotatable

18-fold tool changing magazine at the back of the support,
moving along in the X direction

14-fold tool change magazine PICK-Up system
On the right side of the machine

Drilling unit 7976, 24 spindles, individually available, including:
10 vertical spindles in the X direction
8 vertical spindles in Y direction
pitch 32 mm
Feed stroke 70 mm
3+3 drilling spindles horizontally in the X direction
1+1 drilling spindles horizontally in the Y direction
Rotational speed infinitely variable 1,000 - 6,500 rpm

Groove saw unit fixed in X direction

Drilling unit 7978, 15 spindles, individually available, thereof
13 vertical spindles in the X direction
2 drilling spindles in Y direction
pitch 32 mm
Rotational speed infinitely variable 1,000 - 6,500 rpm

CAMPUS software for CNC machining center consisting of:
1. CAMPUS NC HOPS
Graphic variant system with WOP and CAD/CAM properties
for creating part variants with macro technology
Windows-compliant user interface with a clear display of the workpiece

2. CAMPUS aCADemy
Independent 2-dimensional CAD program for free design or design options.
Geometry adjustment via scaling, rotating, trimming, rounding chamfers, etc.

3. CAMPUS MT manager
Complete tool management on a graphical basis

4. CAMPUS work center
Processing table management

Optionally available processing units:
* Saw unit, tool diam. Max. 220mm
* Horizontal drilling and milling head 4 spindles (cross head)
e.g. also suitable for faceplate milling * Lock case milling unit 1 spindle for
tool shank dia. 16 mm, turning to the left
* Horizontal milling unit

Also optionally available:
* Bar tensioner set consisting of 4 tensioning elements, for
Part height 6 - 50 mm

The tools and HSK mounts shown in the photos are not included in the scope of delivery.
