Glue application width max. 1,300 mm
Application height max. 100 mm

Diameter of application rollers approx. 250 mm
Application rollers rubberized, grooving approx. 13 threads/inch

Diameter of metering rollers approx. 150 mm
Metering rollers rubberized

Upper and lower application units each driven by 1 gear motor, drives frequency-controlled,
Feed speed continuously adjustable via potentiometer

Other equipment:
3 free-running rollers at the inlet.

Operating side of the machine on the right in the direction of thru-feed

Installation length for road operation approx. 970 mm

Overall dimensions:
Length: approx. 1,180 mm
Width: approx. 2,400 mm
Height: approx. 1,560 mm
